PN16 GOST wedge gate valve

GOST 5762-2002 Cast Steel Gate Valve that opens by lifting a round or rectangular gate/wedge out of the path of the fluid. The distinct feature of a gate valve is the sealing surfaces between the gate and seats are planar. The gate faces can form a wedge shape or they can be parallel. Typical gate valves should never be used for regulating flow, unless they are specifically designed for that purpose. On opening the gate valve, the flow path is enlarged in a highly nonlinear manner with respect to percent of opening.

Basic size: DN 50-1600mm

Working pressure: Py10 - 100 MPa

Steel grades: 20, 25L, 09G2S , 20GL, 08(12)Cr18Ni10Ti, 12Cr18Ni9TiL, 10Cr17Ni13Mo2Ti, 12Cr18Ni12Mo3TiL, 08Cr16Ni15Mo3, 15Cr5MoL, 20Cr5MoL, 13HFA

Casted gate valves:

PN10/16 30ch39r, 30ch539r, 30ch939r

PN16 30s41nzh, 30ls41nzh, 30nzh41nzh, 30s941nzh, 30ls941nzh, 30nzh941nzh, 30s541nzh, 30ls541nzh, 30nzh541nzh

PN25 30s64nzh, 30ls64nzh, 30nzh64nzh, 30s964nzh, 30ls964nzh, 30nzh964nzh, 30s927nzh, 30ls927nzh, 30s564nzh, 30ls564nzh, 30nzh564nzh, 30s527nzh, 30ls527nzh

PN40 30s15nzh, 30ls15nzh, 30nzh15zh, 30s915nzh, 30ls915nzh, 30nzh915nzh, 30s515nzh, 30ls515nzh, 30nzh515nzh

PN63 30s76nzh, 30ls76nzh, 30nzh76nzh, 30s976nzh, 30ls976nzh, 30nzh976nzh, 30s576nzh, 30ls576nzh, 30nzh576nzh

PN100/160/250 30s45nzh, 30ls45nzh, 30nzh45nzh, 30s945nzh, 30ls945nzh, 30nzh945nzh, 30s545nzh, 30ls545nzh, 30nzh545nzh
