Carbon steel globe valve, 10inch-300lb

Carbon steel globe valve has the following advantages: 1. Simple structure, more convenient to manufacture and repair; 2. Small working stroke, short opening and closing times; 3. Good sealing, low friction between sealing surfaces, and long life.

Huanqiu valve can manufacture BS1873, API 600, API 602 and DIN globe valves in bolted bonnet and pressure seal design, we also make Y-type globe valve, angle globe valve, bellow seal globe valve. The materials are carbon steel, alloy stainless, and stainless steel.

Design and manufacture: BS 1873, API 600, DIN 3356;

Stainless steel globe valve: ASME B16.34, API 603;

Forged steel globe valve: API 602, BS 5352;

Inspection and Test: API 598, ISO 5208, DIN 3230;

End flange dimension: ASME B16.5 ( for NPS≤24);

ASME B 16.47 series B, API 605 or ASME B 16.47 series A, MSS SP-44(for NPS＞24), DIN 2543-2547.

BW end dimension: ASME B 16.25.

Socket-weld dimension: ASME B 16.11.

Face to face and end to end: ASME B 16.10, DIN 3202.

Pressure-temperature ratings: ASME B 16.34.

Besides the general globe valves, our company also can make cryogenic globe valve, bellow seal globe valve and extended stem globe valve. We can also make the different material according to user’s requirement, likely Monel, Hastelloy C, Inconel, Alloy 20 and so on.
